Version v1.0R - switch - powered, with PoE passthrough - smart - 5 x Gigabit Ethernet - wall-mountable - PoE++ (60 W) - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | TRENDnet TPE-B541 - Version v1.0R - switch - powered, with PoE passthrough - 5 ports - smart - TAA Compliant |
| Device Type | Switch - 5 ports - smart |
| Subtype | Gigabit Ethernet |
| Ports | 5 x Gigabit Ethernet |
| Power Over Ethernet (PoE) | PoE++ |
| PoE Budget | 60 W |
| Performance | Switching capacity: 10 Gbps ¦ Forwarding rate (64?byte packets): 7.44 Mpps |
| Capacity | RAM buffer: 512 KB ¦ VLAN groups: up to 32 |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 10KB |
| Remote Management Protocol | RSTP |
| Features | LED status indicators, PoE Pass Through, RSTP, VLAN support, QoS, IGMP snooping, Voice VLAN, per port bandwidth control, fanless, metal housing, half duplex mode, full duplex mode, STP support, RSTP support, port-based QoS, CoS, queue scheduling support, port-based VLAN, port isolation, IGMP snooping v2, storm protection, auto-negotiation, PoE powered |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w |
| Dimensions (WxDxH) | 6.7 in x 4.1 in x 1.1 in |
| Weight | 15.87 oz |
| TAA Compliant | Yes |
| Manufacturer Warranty | Limited lifetime warranty |
| General | |
| Device Type | Switch - 5 ports - smart |
| Enclosure Type | Wall-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 5 x Gigabit Ethernet |
| Power Over Ethernet (PoE) | PoE++ |
| PoE Budget | 60 W |
| Performance | Switching capacity: 10 Gbps ¦ Forwarding rate (64?byte packets): 7.44 Mpps |
| Capacity | RAM buffer: 512 KB ¦ VLAN groups: up to 32 |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 10KB |
| Remote Management Protocol | RSTP |
| Features | LED status indicators, PoE Pass Through, RSTP, VLAN support, QoS, IGMP snooping, Voice VLAN, per port bandwidth control, fanless, metal housing, half duplex mode, full duplex mode, STP support, RSTP support, port-based QoS, CoS, queue scheduling support, port-based VLAN, port isolation, IGMP snooping v2, storm protection, auto-negotiation, PoE powered |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w |
| Status Indicators | Link/activity, power, PoE, speed/activity |
| Expansion / Connectivity | |
| Interfaces | 1 x Gigabit LAN RJ-45 PoE++ input - 90 W ¦ 4 x Gigabit LAN RJ-45 PoE+ output |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Miscellaneous | |
| MTBF | 503,726 hours |
| Compliant Standards | NDAA, FCC, LVD |
| TAA Compliant | Yes |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 6.7 in |
| Depth | 4.1 in |
| Height | 1.1 in |
| Weight | 15.87 oz |
