Application accelerator - 10GbE - 1U - factory integrated - rack-mountable
| Main Specifications | |
|---|---|
| Product Description | Nutanix NX-8170-G9 - application accelerator |
| Device Type | Application accelerator |
| Form Factor | Rack-mountable - 1U |
| Processor | 2 x Intel Xeon Silver 4416+ - 2 GHz |
| RAM | 4096 MB (max) |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
| Power | AC 208-240 V |
| Pricing Type | Factory integrated |
| Environmental Standards | ENERGY STAR Qualified |
| Dimensions (WxDxH) | 17.3 in x 29.4 in x 1.7 in |
| Weight | 41.89 lbs |
| General | |
| Device Type | Application accelerator |
| Height (Rack Units) | 1U |
| Width | 17.3 in |
| Depth | 29.4 in |
| Height | 1.7 in |
| Weight | 41.89 lbs |
| Expansion / Connectivity | |
| Expansion Bays | 12 (total) / 12 (free) x hot-swap |
| Expansion Slots | 2 (total) / 2 (free) x M.2 |
| Interfaces | 2 x 10GBase-T - RJ-45 ¦ 1 x IPMI - RJ-45 ¦ 2 x 10GBase-T - SFP+ ¦ 1 x VGA - HD-15 |
| Miscellaneous | |
| Compliant Standards | BIS, BSMI, CSA, CSA-US, EAC, Energy Star, FCC, ICES, KCC, RCM, REACH, RoHS, Argentina S-Mark, SABS, SII, UKCA, UkrSEPRO, UL, VCCI-A, WEEE, cUL |
| Pricing Type | Factory integrated |
| Networking | |
| Form Factor | Rack-mountable |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
| Status Indicators | Power, drive, port status |
| Features | 40mm chassis fan, 8 fans |
| Power | |
| Power Device | Internal power supply |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Voltage Required | AC 208-240 V |
| Power Provided | 2000 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 86 °F |
| Humidity Range Operating | 20 - 85% |
| Processor / Memory / Storage | |
| Processors Installed | 2 x Intel Xeon Silver 4416+ 2 GHz |
| Max Supported Qty | 2 |
| RAM | (4096 MB max) DIMM 288-pin |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 69.89 lbs |
| Environmental Standards | |
| ENERGY STAR Certified | Yes |
