Eaton - Eaton Tripp Lite Series PDU Monitored Horizontal 3.3/3.8KW 208/240V ATS L6-20R 2 L6-20P 1U
Power distribution unit (rack-mountable) - 20 A - AC 200/208/220/230/240 V - 3.8 kW - 1-phase - Ethernet 10/100 - input: NEMA L6-20 - output connectors: 1 (NEMA L6-20) - 1U - 19" - 10 ft cord
Eaton
PDUMNH20HVAT
0037332187932
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series PDU Monitored Horizontal 3.3/3.8KW 208/240V ATS L6-20R 2 L6-20P 1U - power distribution unit - 3.8 kW |
| Device Type | Power distribution unit - rack-mountable |
| Cord Length | 10 ft |
| Rack Size | 19" - 1U |
| Weight | 15.21 lbs |
| Input Wiring | 1-phase |
| Input Voltage | AC 200/208/220/230/240 V |
| Output Voltage | AC 200/208/220/230/240 V |
| Power Capacity | 3.8 kW |
| Input Connectors | 2 x power NEMA L6-20 |
| Output connectors | 1 x power NEMA L6-20 |
| Networking | Ethernet 10/100 |
| Remote Management Protocol | SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH |
| Dimensions (WxDxH) | 16.9 in x 14 in x 1.7 in |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | Power distribution unit - rack-mountable |
| Height (Rack Units) | 1U |
| Rack Size | 19" |
| Cord Length | 10 ft |
| Expansion / Connectivity | |
| Interfaces | 1 x management (Ethernet) - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Cables Included | 2 x power cable - integrated - 10 ft |
| Rack Mounting Kit | Included |
| Features | LED display, voltage monitoring, current meter, Automatic Transfer Switch (ATS), AC frequency monitoring, real power meter, power factor meter |
| Compliant Standards | FCC Class A certified, NOM, RoHS, UL 60950-1, CSA 22.2 No. 60950-1 |
| Networking | |
| Remote Management Interface | Ethernet 10/100 |
| Remote Management Protocol | SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH |
| Software / System Requirements | |
| Software Included | TrippLite PowerAlert |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Power Device | |
| Input Voltage | AC 200/208/220/230/240 V |
| Frequency Provided | 50/60 Hz |
| Input Wiring | 1-phase |
| Input Connectors | 2 x power NEMA L6-20 |
| Power Output Connectors Details | 1 x power NEMA L6-20 |
| Output Voltage | AC 200/208/220/230/240 V 50/60 Hz |
| Max Electric Current | 20 A |
| Power Capacity | 3.8 kW |
| Dimensions & Weight | |
| Width | 16.9 in |
| Depth | 14 in |
| Height | 1.7 in |
| Weight | 15.21 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 21.7 in |
| Shipping Depth | 20.7 in |
| Shipping Height | 7.5 in |
| Shipping Weight | 16.69 lbs |
