Server Technology - Server Technology PRO4X C4W48RA-2CBE2FD7
Power distribution unit (rack-mountable) - switched - AC 208 V - 5 kW - 1-phase - Ethernet 10/100/1000, RS-232 - input: NEMA L6-30P - output connectors: 48 (24 x IEC 60320 C13, 24 x IEC 60320 Cx) - 0U
Server Technology
C4W48RA-2CBE2FD7
N/A
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | Server Technology PRO4X C4W48RA-2CBE2FD7 - power distribution unit - switched - 5 kW |
| Device Type | Power distribution unit - rack-mountable |
| Rack Size | 0U |
| Input Wiring | 1-phase |
| Input Voltage | AC 208 V |
| Output Voltage | AC 208 V |
| Power Capacity | 5 kW |
| Input Connectors | 1 x power NEMA L6-30P |
| Output connectors | 12 x power IEC 60320 C13 - 208 V 12 A ¦ 24 x power IEC 60320 Cx - 208 V 16 A |
| Networking | Ethernet 10/100/1000, RS-232 |
| Remote Management Protocol | HTTP, HTTPS, SSH, Telnet, SNMP, Syslog, LDAP, LDAPS, SSH-2, SNMP 2c, SNMP 3, IPv4, IPv6, LDAP 3.0, TACACS+, RADIUS, SFTP |
| Dimensions (WxDxH) | 2.2 in x 3.1 in x 80 in |
| General | |
| Device Type | Power distribution unit - rack-mountable |
| Height (Rack Units) | 0U |
| Expansion / Connectivity | |
| Interfaces | 2 x management (Gigabit Ethernet) - RJ-45 ¦ 2 x sensor - RJ-9 ¦ 1 x PDU link - RJ-12 ¦ 2 x USB-A - 4 pin USB Type A ¦ 1 x USB - 4 pin USB Type B |
| Miscellaneous | |
| Features | Waveform capture, alternating-phase outlets, Ramlock Locking Outlets, Branch Circuit Protection, 45° angled infeed, voltage monitoring, Per Input Power Sensing (PIPS), Per Outlet Power Sensing (POPS), overcurrent protection, Branch Current Monitoring, multi-color LCD, Multi-Unit Linking and Cascading, voltage meter, network monitoring, outlet control, crest factor meter, energy meter, email alerts support, environmental sensor ready, locking outlets, power factor meter, apparent power meter, active power meter, current meter |
| Compliant Standards | UL 94V-0, UL, IEC 62368, UL 489, cTUVus, UL 62368-1, CSA C22.2 No. 62368-1, EMC, FCC Part 15 Subpart B, ICES-003 Class A, CAN |
| Networking | |
| Remote Management Interface | Ethernet 10/100/1000, RS-232 |
| Remote Management Protocol | HTTP, HTTPS, SSH, Telnet, SNMP, Syslog, LDAP, LDAPS, SSH-2, SNMP 2c, SNMP 3, IPv4, IPv6, LDAP 3.0, TACACS+, RADIUS, SFTP |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 5 - 90% RH (non-condensing) |
| Power Device | |
| Input Voltage | AC 208 V |
| Input Wiring | 1-phase |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x power NEMA L6-30P |
| Power Output Connectors Details | 12 x power IEC 60320 C13 - 208 V 12 A ¦ 24 x power IEC 60320 Cx - 208 V 16 A |
| Output Voltage | AC 208 V |
| Max Electric Current | 30 A |
| Power Capacity | 5 kW |
| Circuit Protection | Circuit breaker |
| Dimensions & Weight | |
| Width | 2.2 in |
| Depth | 3.1 in |
| Height | 80 in |
