StarTech - Startech USB-C to Ethernet Adapter, NIC, 1Gbps
Network adapter - USB-C 3.2 Gen 1 - Gigabit Ethernet + USB-C 3.2 Gen 1 - space gray
Product Description
Additional Details
- Special Delivery: None
What's Included
| Main Specifications | |
|---|---|
| Product Description | Startech USB-C to Ethernet Adapter, NIC, 1Gbps - network adapter - USB-C 3.2 Gen 1 - Gigabit Ethernet + USB-C 3.2 Gen 1 |
| Device Type | Network adapter |
| Form Factor | External |
| Interface (Bus) Type | USB-C 3.2 Gen 1 |
| Ports | Gigabit Ethernet + USB-C 3.2 Gen 1 |
| Dimensions (WxDxH) | 0.9 in x 0.6 in |
| Weight | 0.87 oz |
| Cabling Type | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE |
| Data Transfer Rate | 1 Gbps |
| Capacity | Jumbo frame size: 9000 |
| Processor | Realtek Semiconductor RTL8153B |
| Compliant Standards | IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x |
| Color | Space gray |
| System Requirements | Android, Google Chrome OS, Apple iOS, Apple MacOS X 10.11 - 10.15, Apple macOS Big Sur 11.0, Apple macOS Monterey 12.0, Microsoft Windows 7 / 8 / 8.1 / 10 / 11, Apple macOS Ventura 13.0, Linux Kernel 2.4.20 or later (LTS versions only), Windows 10 (on ARM), Apple macOS Sonoma 14.0, Windows 11 (on ARM), Microsoft Windows Server 2008 R2 / 2012 R2 / 2016 / 2022 |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | Network adapter |
| Form Factor | External |
| Interface (Bus) Type | USB-C 3.2 Gen 1 |
| Expansion / Connectivity | |
| Interfaces | 1 x 1000Base-T - RJ-45 - female ¦ 1 x USB 3.2 Gen 1 - 24 pin USB-C - female |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Cables Included | 1 x USB-C cable (integrated) - 5.9 in |
| MTBF | 1,912,948 hours |
| Compliant Standards | FCC, RoHS, WEEE, RCM, USB Power Delivery 3.0 |
| Color | Space gray |
| Networking | |
| Ports | Gigabit Ethernet + USB-C 3.2 Gen 1 |
| Connectivity Technology | Wired |
| Cabling Type | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Data Transfer Rate | 1 Gbps |
| Capacity | Jumbo frame size: 9000 |
| Status Indicators | Link/activity, speed |
| Features | WOL, auto-uplink (auto MDI/MDI-X), full duplex mode, USB powered, PXE support, VLAN Tagging, promiscuous mode, USB Power Delivery (up to 100 watt), Thunderbolt compatible |
| Compliant Standards | IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x |
| Software / System Requirements | |
| OS Required | Android, Google Chrome OS, Apple iOS, Apple MacOS X 10.11 - 10.15, Apple macOS Big Sur 11.0, Apple macOS Monterey 12.0, Microsoft Windows 7 / 8 / 8.1 / 10 / 11, Apple macOS Ventura 13.0, Linux Kernel 2.4.20 or later (LTS versions only), Windows 10 (on ARM), Apple macOS Sonoma 14.0, Windows 11 (on ARM), Microsoft Windows Server 2008 R2 / 2012 R2 / 2016 / 2022 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 10 - 85% RH (non-condensing) |
| Processor / Memory | |
| Processor | Realtek Semiconductor RTL8153B |
| Dimensions & Weight | |
| Depth | 0.9 in |
| Height | 0.6 in |
| Weight | 0.87 oz |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 8.7 in |
| Shipping Depth | 5 in |
| Shipping Height | 0.6 in |
| Shipping Weight | 0.95 oz |
