Fluke - Fluke LinkIQ LIQ-KIT-FMC
Network tester kit
Product Description
Additional Details
- Special Delivery: None
What's Included
| Main Specifications | |
|---|---|
| Product Description | Fluke LinkIQ LIQ-KIT-FMC - network tester kit |
| Device Type | Network tester kit |
| Cable Types | STP, UTP |
| Tests, Tools and Measurements | PoE, length, bandwidth, toning, pair length, tests for split pairs, wiremap |
| Features | Port Blink, USB-C connectivity, Link Layer Discovery Protocol (LLDP), Cisco Discovery Protocol (CDP), Fast Link Pulses (FLP), VLAN support, tests up to 305 m, cable tone generator, Remote Office Locators, Analog and Digital Toning |
| Power | 100-240 V |
| Dimensions (WxDxH) | 4.5 in 8.5 in |
| Weight | 22.01 oz |
| General | |
| Device Type | Network tester kit |
| Kit Content | 7 x ID remotes, IntelliTone Pro 200 Probe, LinkIQ Cable+Network Tester, FMC-10G fiber media converter kit |
| Media | Copper |
| Features | Port Blink, USB-C connectivity, Link Layer Discovery Protocol (LLDP), Cisco Discovery Protocol (CDP), Fast Link Pulses (FLP), VLAN support, tests up to 305 m, cable tone generator, Remote Office Locators, Analog and Digital Toning |
| Tests, Tools and Measurements | PoE, length, bandwidth, toning, pair length, tests for split pairs, wiremap |
| Cable Types | STP, UTP |
| Included Accessories | Power charger, carrying case |
| Cables Included | RJ-45 to RJ-45 patch cable ¦ RJ-45 to RJ-11 modular adapter |
| Connectors | RJ-45 |
| Compliant Standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
| Power | |
| Input Voltage | 100-240 V |
| Output Voltage | 15 V |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Min Storage Temperature | 14 °F |
| Max Storage Temperature | 140 °F |
| Humidity Range Operating | 0 - 90% (non-condensing) |
| Vibration Tolerance (operating) | 2 g @ 5-500 Hz |
| Drop Specification | 3.3 ft |
| Battery | |
| Technology | Lithium ion |
| Voltage | 3.6 V |
| Run Time (Up To) | 8 hour(s) |
| Display | |
| Technology | LCD |
| Display Resolution | 800 x 480 pixels |
| Color Support | Color |
| Features | Touchscreen |
| Dimensions & Weight | |
| Width | 4.5 in |
| Height | 8.5 in |
| Weight | 22.01 oz |
