StarTech - Startech
Network adapter - PCIe 3.0 x2 low profile - 5GBase-T x 1 - black - TAA Compliant
Product Description
What's Included
| Main Specifications | |
|---|---|
| Product Description | Startech - network adapter - PCIe 3.0 x2 - 5GBase-T x 1 - TAA Compliant |
| Device Type | Network adapter |
| Form Factor | Plug-in card - low profile |
| Interface (Bus) Type | PCI Express 3.0 x2 |
| PCI Specification Revision | PCIe 3.0 |
| Ports | 5GBase-T x 1 |
| Dimensions (WxDxH) | 0.7 in x 4.8 in x 3.4 in |
| Weight | 2.07 oz |
| Cabling Type | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T, Ethernet 2.5GBase-T, Ethernet 5GBase-T |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE, 5GbE, 2.5GbE |
| Data Transfer Rate | 5 Gbps |
| Capacity | Jumbo frame size: 9000 |
| Processor | Realtek Semiconductor RTL8126 |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1ad, IEEE 802.3az, IEEE 802.1Qav, IEEE 802.3bz |
| Color | Black |
| System Requirements | Microsoft Windows Server 2019, Ubuntu Linux 20.04, Microsoft Windows Server 2022, Microsoft Windows 10 / 11 |
| TAA Compliant | Yes |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | Network adapter |
| Form Factor | Plug-in card - low profile |
| Interface (Bus) Type | PCI Express 3.0 x2 |
| PCI Specification Revision | PCIe 3.0 |
| Expansion / Connectivity | |
| Interfaces | 2 x 5GBase-T - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Included Accessories | Low-profile bracket |
| Compliant Standards | FCC, RoHS |
| Color | Black |
| TAA Compliant | Yes |
| Networking | |
| Ports | 5GBase-T x 1 |
| Connectivity Technology | Wired |
| Cabling Type | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T, Ethernet 2.5GBase-T, Ethernet 5GBase-T |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 5 Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Data Transfer Rate | 5 Gbps |
| Capacity | Jumbo frame size: 9000 |
| Status Indicators | Link/activity/speed |
| Features | Auto-negotiation, VLAN support, WOL, bus powered |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1ad, IEEE 802.3az, IEEE 802.1Qav, IEEE 802.3bz |
| Software / System Requirements | |
| OS Required | Microsoft Windows Server 2019, Ubuntu Linux 20.04, Microsoft Windows Server 2022, Microsoft Windows 10 / 11 |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 149 °F |
| Processor / Memory | |
| Processor | Realtek Semiconductor RTL8126 |
| Dimensions & Weight | |
| Width | 0.7 in |
| Depth | 4.8 in |
| Height | 3.4 in |
| Weight | 2.07 oz |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 4.23 oz |
