Planar - Planar HD 173
Luminate Ultra W Series LED video wall - MicroLED - interactive digital signage - 1920 x 1080 173"
Product Description
What's Included
| Main Specifications | |
|---|---|
| Product Description | Planar HD 173 Luminate Ultra W Series LED video wall - MicroLED - for digital signage / interactive communication |
| Product Type | LED video wall - MicroLED |
| Diagonal Size | 173" |
| Commercial Use | Yes - interactive digital signage |
| Video Wall Resolution | 1920 x 1080 |
| Frame Rate & Enhancement Technology | 3840 Hz Frame Rate |
| Video Interface | HDMI |
| LCD Backlight Technology | LED backlight |
| Included Accessories | Remote control, wall mount, trim kit, video controller, signal cables, spare module, power cables |
| Voltage | (50/60 Hz) |
| Dimensions (WxDxH) - with wall mounting | 151.2 in x 3.8 in x 85.2 in |
| Weight | 751 lbs |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED video wall - MicroLED |
| Commercial Use | Yes - interactive digital signage |
| Series | Luminate Ultra W Series |
| TV Tuner Presence | No |
| Video Interface | HDMI |
| Dimensions | With wall mounting |
| Width | 151.2 in |
| Depth | 3.8 in |
| Height | 85.2 in |
| Weight | 751 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | Wall mount, trim kit, video controller, signal cables, spare module, power cables |
| Cables Included | Signal cable kit ¦ Power cable |
| Compliant Standards | IP65 front, IP65 back |
| Power | |
| Power Device | Power supply |
| Input Voltage | (50/60 Hz) |
| Video Wall Display Unit Power Consumption (Max) | 7650 W |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 10 - 80% RH (non-condensing) |
| Display | |
| Pixel Pitch | 2 mm |
| Frame Rate & Enhancement Technology | 3840 Hz Frame Rate |
| LCD Backlight Technology | LED backlight |
| Color Temperature | 3000 - 10000K |
| Image Contrast Ratio | 10000:1 |
| Brightness | 3000 cd/m² |
| Viewing Angle | 170° |
| Viewing Angle (Vertical) | 170° |
| Operation Hours / Days | 24 / 7 |
| Additional Features | 97% brightness uniformity, Glue-on-Board (GOB) surface treatment technology, front serviceability |
| Remote Control | |
| Type | Remote control |
| Stands & Mounts | |
| Wall Mount Included | Yes |
| Video Wall | |
| Resolution | 1920 x 1080 |
| Diagonal Size | 173" |
