Planar - Planar SLE55
55" Diagonal Class Simplicity E Series LED-backlit LCD display - digital signage - 4K UHD (2160p) 3840 x 2160 - direct-lit LED
Product Description
What's Included
| Main Specifications | |
|---|---|
| Product Description | Planar SLE55 Simplicity E Series - 55" LED-backlit LCD display - 4K - for digital signage |
| Product Type | LED-backlit LCD flat panel display |
| Diagonal Class | 55" |
| Commercial Use | Yes - digital signage |
| Country Kits | Europe, United States |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Frame Rate & Enhancement Technology | 60 Hz Frame Rate |
| Video Interface | HDMI |
| HDMI Ports Qty | 3 ports |
| Connectivity | LAN, Bluetooth, Wi-Fi |
| LCD Backlight Technology | Direct-lit LED |
| Image Aspect Ratio | 16:9 |
| TV Tuner | No tuner |
| Commercial Features | Digital signage |
| Picture Enhancements | 90% DCI-P3 color gamut |
| Speaker System | 2 speakers |
| Storage Capacity | 32 GB (available 24 GB) |
| USB | 2 ports |
| Included Accessories | Remote control, power cable (EU, 1.8 m), power cable (US, 1.8 m), wall mount, mounting kit |
| Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 135 Watt |
| Power Consumption Stand by | 0.5 Watt |
| Dimensions (WxDxH) | 48.8 in x 2.8 in x 27.9 in |
| Weight | 28.66 lbs |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Power Consumption Operational | 135 Watt |
| Diagonal Class | 55" |
| Commercial Use | Yes - digital signage |
| Series | Simplicity E Series |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Sensors | Infrared (IR) |
| Video Interface | HDMI |
| HDMI Ports Qty | 3 ports |
| Modes | Portrait mode, landscape mode |
| Picture Enhancements | 90% DCI-P3 color gamut |
| Cooling System | Fanless |
| Width | 48.8 in |
| Depth | 2.8 in |
| Height | 27.9 in |
| Weight | 28.66 lbs |
| Country Kits | Europe, United States |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - advanced exchange program - 3 years |
| Miscellaneous | |
| Included Accessories | Power cable (EU, 1.8 m), power cable (US, 1.8 m), wall mount, mounting kit |
| Cables Included | HDMI cable - 6 ft ¦ Serial cable - 3.3 ft |
| Compliant Standards | HDCP 1.4, HDCP 2.3, CEC, FCC Class B certified, cTUVus, RoHS, HDCP 2.2 |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Stand by | 0.5 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 80% RH (non-condensing) |
| Display | |
| Pixel Pitch | 0.315 mm |
| Color Support | 1000000000 colors |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Image Aspect Ratio | 16:9 |
| Frame Rate & Enhancement Technology | 60 Hz Frame Rate |
| LCD Backlight Technology | Direct-lit LED |
| Coating | 25% haze, 3H Hard |
| Image Contrast Ratio | 4000:1 |
| Brightness | 500 cd/m² |
| Viewing Angle | 178° |
| Response Time | 8 ms |
| Backlight Life | 50,000 hours |
| Commercial Features | Digital signage |
| Operation Hours / Days | 24 / 7 |
| Additional Features | Designed for 24/7 operation |
| Connections | |
| Connector Type | 3 x HDMI input ¦ USB 3.0 ¦ USB 2.0 ¦ Audio line-out ¦ LAN ¦ RS-232 |
| Remote Control | |
| Type | Remote control |
| Audio System | |
| Speaker System | 2 speakers |
| Speakers | 2 x speaker - 10 Watt |
| Dimensions & Weight (Shipping) | |
| Weight (Shipping) | 40.79 lbs |
| Network & Internet Multimedia | |
| Connectivity | LAN, Bluetooth, Wi-Fi |
| LAN Protocol | Ethernet |
| Wi-Fi Protocol | 802.11b, 802.11g, 802.11n |
| Bluetooth Version | Bluetooth 5.0 |
| Stands & Mounts | |
| Flat Panel Mount Interface | 400 x 400 |
| VESA Compatibility | Yes |
| Media Player | |
| USB Port | Yes |
| USB Ports Qty | 2 |
| Configuration | 32 GB (available 24 GB) |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
