Axis Communications - Axis D6310
Air quality sensor - wired - 10/100/1000 Ethernet - NCS S 1002-B, white - TAA Compliant
Axis Communications
03202-001
7331021090675
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | Axis D6310 - air quality sensor - NCS S 1002-B, white - TAA Compliant |
| Product Type | Air quality sensor |
| Environment | Indoor |
| Sensor Type | Air quality, humidity, carbon dioxide, particulate matter, Volatile Organic Compounds (VOC) sensor, nitrogen dioxide |
| Placing / Mounting | Ceiling-mounting, wall-mounting |
| Functions | Air quality measurement |
| Integrated Sensors | Passive infrared motion sensor (PIR) |
| Integrated Components | Speaker, microphone |
| Power Source | PoE |
| Connectivity | Wired - 10/100/1000 Ethernet |
| Color | NCS S 1002-B, white |
| TAA Compliant | Yes |
| Manufacturer Warranty | 5-year warranty |
| Dimensions (WxDxH) | 5.9 in x 5.9 in x 2.4 in |
| Designed For | AXIS TP3101 |
| General | |
| Product Type | Air quality sensor |
| Sensor Type | Air quality, humidity, carbon dioxide, particulate matter, Volatile Organic Compounds (VOC) sensor, nitrogen dioxide |
| Environment | Indoor |
| Functions | Air quality measurement |
| Integrated Components | Speaker, microphone |
| Integrated Sensors | Passive infrared motion sensor (PIR) |
| Power Source | PoE |
| Placing / Mounting | Ceiling-mounting, wall-mounting |
| Connectivity Technology | Wired - Gigabit Ethernet, Fast Ethernet, Ethernet |
| Interfaces Details | Gigabit Ethernet ¦ Serial (RS-422/RS-485) |
| Features | Two-way communication, visual alert, 16:9 aspect ratio, H.264 compression standard, H.265 compression standard, Motion JPEG support, full duplex support, echo cancellation, LED status indicators, audio detection, cigarette smoking detection, vandal-resistant RTSP support, IPv4 support, IPv6 support, HTTP support, HTTPS support, TLS encryption, QoS Layer 3 DiffServ support, FTP support, SFTP support, CIFS/SMB support, SMTP support, mDNS, UPnP, DNS/DNSv6 support, DDNS (Dynamic Domain Name Service), NTP support, NTS support, RTP support, SRTP/RTSPS support, UDP, RTCP support, TCP support, DHCPv4/v6 support, SSH support, CDP, MQTT v3.1.1 support, Syslog support |
| Temperature Range | -10 - 45 °C |
| Measurement Accuracy | ±1 °C |
| Miscellaneous | |
| Included Accessories | Mounting kit |
| Product Material | Plastic, aluminum |
| Color | NCS S 1002-B, white |
| Encryption Algorithm | FIPS 140 |
| Warranty | 5-year warranty |
| Power Consumption Operational | 2.8 Watt |
| Compliant Standards | IPv4, IPv6, USGv6, TLS, IEEE 802.1x, IEEE 802.1ar, UL, FCC Part 15 A, KC, VCCI, RCM, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, AS/NZS CISPR 32 Class A, ICES-3(A)/NMB-3(A), VCCI Class A, KS C 9835, KS C 9832 Class A, IEC/EN/UL 62368-1, CAN/CSA-C22.2 No. 62368-1 Third Edition, IEC/EN 60825-1:2014 Class 1, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 62262 IK08, ETSI EN 303 645, NIST SP500-267, EN/IEC 63000:2018, RoHS 2011/65/EU Amendment 2015/863, SCIP, REACH 1907/2006/CE |
| TAA Compliant | Yes |
| Processor | |
| CPU | AML8726-MXS |
| RAM | |
| Installed Size | 1 GB |
| Environmental Parameters | |
| Min Operating Temperature | 14 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 0 - 90% RH (non-condensing) |
| Flash Memory | |
| Installed Size | 8 GB |
| Dimensions & Weight | |
| Width | 5.9 in |
| Depth | 5.9 in |
| Height | 2.4 in |
| Weight | 29.27 oz |
| Compatibility Information | |
| Designed For | AXIS TP3101 |
| Motion Sensor | |
| Detection Mode | Passive infrared (PIR) |
| Detection Range | 16.4 ft |
| Control Unit | |
| Operating System | AXIS OS |
