StarTech.com - StarTech.com
Patch panel - 110 punch-down - rack mountable - CAT 6 - UTP - RJ-45 X 48 - black - 2U - 19"
StarTech.com
CPANEL48
0065030915076
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | StarTech.com patch panel - 2U - 19" - 110 punch-down |
| Product Type | Patch panel - CAT 6 - RJ-45 X 48 - 110 punch-down |
| Placing / Mounting | Rack mountable |
| Package Content | Screws, mounting nuts |
| Dimensions (WxDxH) | 19 in x 3.5 in x 1.3 in |
| Weight | 34.56 oz |
| Product Material | Steel |
| Color | Black |
| Port Qty | 48 ports |
| Height (Rack Units) | 2U |
| Wiring Scheme | T568A/B |
| Compliant Standards | RoHS, WEEE, ANSI/TIA-568-C.2 |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Product Type | Patch panel - CAT 6 - 110 punch-down |
| Placing / Mounting | Rack mountable |
| Package Content | Screws, mounting nuts |
| Product Material | Steel |
| Height (Rack Units) | 2U |
| Width | 19 in |
| Depth | 3.5 in |
| Height | 1.3 in |
| Weight | 34.56 oz |
| Enclosure Color | Black |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Rack Size | 19" |
| Mounting Kit | Included |
| Features | Color-coded, numbered, powder-coated, up to 1 Gbps data transfer |
| Compliant Standards | RoHS, WEEE, ANSI/TIA-568-C.2 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 158 °F |
| Humidity Range Operating | 0 - 50% |
| Cabling & Wiring | |
| Port Qty | 48 ports |
| Termination Type | 110 type termination punchdown |
| Technology | Unshielded twisted pair (UTP) |
| Wiring Scheme | T568A/B |
| Features | Gold-plated contacts |
| Connector Provided | 48 x RJ-45 female |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 20.3 in |
| Shipping Depth | 4.7 in |
| Shipping Height | 3 in |
| Shipping Weight | 3.31 lbs |
